NSF 61 Approved Industrial Water Storage Tanks For fire water
Storage
Site Assembled industrial water storage Tanks for the storage of
firewater (sprinkler tanks): Center Enamel GLS industrial water
storage tanks are to suit individual customer requirements and
local conditions. High-quality designs that meet a wide range of
international standards, constructed from corrosion-resistant
materials. Tanks can be designed that meet earthquake and high wind
conditions. Benefits of the system include ease and speed of
installation - use of hydraulic jacks - Simplicity of foundations -
no need for support steel work or dwarf walls.
We have uniquely positioned ourselves as a dependable supplier of
Fire Water Tanks. These fire water tanks are atmospheric water
storage tanks specifically designed for use in residential,
commercial or institutional buildings. Offered fire water tanks are
well tested on numerous parameters in order to ensure us
flawlessness.
Rapid, safe & effective hydraulic jack installation: No need for
scaffolding or working at height. Our cylindrical tanks are
effectively built from the top down, using the latest hydraulic
jack technology.
Site assembled industrial water Storage Tanks for the storage of
process water & drinking water is also available from the same
manufacturer.
Center Enamel industrial water tanks are available in a range of
sizes and configurations, up to 25000m³. Consisting of bolted steel
panels, waterproof steel cover , our industrial water storage tanks
are designed to be built safely and quickly on site by a small team
of trained technicians.
Our industrial water storage tanks also call Glass-Fused-to-Steel
tanks, are made of special steel plate, special sealant,
self-locking bolt. That is why the industrial water storage tanks
can be dismantled, removed and relocated. The special steel plate
is coated with two layers of enamel coating on both side. After the
heat polymerization, a strong binding force is formed between the
coating and the steel plate, which make the Glass-Fused-to-Steel
tanks have Good chemical and physical performance. All our
Glass-Fused-to-Steel tank products are manufactured to meet or
exceed common government regulations and industry standards: AWWA
D103-09 , OSHA, ISO/EN28765. So glass lined steel industrial water
storage tanks are very suitable for wastewater treatment
engineering, including mixing tanks, flocculation tanks,
sedimentation tanks and others.
In addition to comprehensive manufacturing and superior service,
Center Enamel delivers customized tank fabrication to suit the
needs of your location. Our storage tanks designers with decades of
experience in tank production turn your specifications into a
specialized tank built to last. Center Enamel provides the
industry's leading quality ratings, with customer testimonials and
reviews to support each product.
All Center Enamel Glass-Fused-to-Steel tank’s capabilities can be
expanded and relocated, which allow the factory to relocate the
glass lined steel industrial water storage tanks when the factory
moving to another place. Center Enamel tank’s storage capacities
are made flexible by adding or removing a ring of side staves. All
tanks can be shipped worldwide in containers which reduce freight
charges and allow for easier handling.
glass lined steel industrial water storage tanks Specifications
| Coating color | dark blue, dark green , white, and customized |
| A standard steel plate size | effective size 2400mm x 1200 m |
| Steel plates thickness | 3mm - 12mm , depends on the diameter & height |
| Coating thickness | 0.25mm - 0.4mm, two coating internal and external |
| Acid and alkalinity proof | standard coating suits for PH3 - PH11, special coating suits for
PH1 - PH14 |
| Adhesion | 3,450N/cm |
| Elastic | same as steel sheet , around 500KN/mm |
| Hardness | 6.0 Mohs |
| Service life | >30 years |
| Spark test | >1500 V |
| Permeability | gas and liquid impermeable |
| Easy yo clean | smooth, glossy, inert, anti-adhesion |
| Corrosion resistance | excellent ! Suitable for waste water salt water, sea water, high
sulfur crude oil, salt fox, organic and inorganic compounds
|
glass lined steel industrial water storage tanks Manufacturer
Center Enamel Co., Ltd is not only the first Glass-Fused-to-Steel
Tanks manufacturer and supplier in China but also the most
experienced Glass-Fused-to-Steel tanks manufacturer in all of Asia.
Center Enamel Glass-Fused-to-Steel tanks engineering & design,
product testing and quality system are in strict accordance with
AWWA D103-09, OSHA, ISO/EN 28765, NSF61 and NFPA etc. international
standards. CEC Glass-Fused-to-Steel tanks are widely used in
drinking/potable water, industrial effluents, municipal sewage,
bio-energy, landfill leachate, agriculture etc. applications. Until
2020, Center Enamel Glass-Fused-to-Steel tanks have been exported
to more than 90 countries including USA, Australia, Canada,
Malaysia, Indonesia, Russia, UAE, Panama, India and South Africa
etc. The superior product quality and prompt service gain us
worldwide recognition.
glass lined steel industrial water storage tanks Project References
